Automatic Discharge Disc Bowl Oil Separator for Soybean Oil

Name: Automatic Discharge Disc Bowl Oil Separator for Soybean Oil
Brand: Juneng
Price: 78 USD

Wholesale Automatic Discharge Disc Bowl Oil Separator for Soybean Oil from china suppliers

Place of Origin : Jiangsu, China

product type : Oil

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Bearing, Motor

Brand Name : Juneng

voltage : 220V/380V/460V

power(w) : depend on the model

dimension(l*w*h) : According with the model

warranty : 12 months

key selling points : Easy To Operate

Capacity : 6000-15000L/H, Diffrent Capacity

Weight (KG) : 2200

setting speed : 6000RPM

After-sales Service Provided : Engineers available to service machinery overseas

Name : Automatic Discharge Disc Bowl Oil Separator

Processing Types : Edible Oil

Processing : Other

Material : Food Grade Stainless Steel

Control system : PLC

Certification : CE,ISO,BV

Type : Separating Plant

Applicable Industries : Food & Beverage Factory

MOQ : 1 set

Price : $78,166-78,600 / set

Contact Now

Product Description

Product Application

DHZ series automatic discharging separator is special equipment for oil and fat refining, it has the traits as high rotating speed, operation stability, completely sealed up of the inlet and outlet system, lower noise and fine separating affection.

Juneng Separator can suitable for a variety of oils and fats and provide personalized solutions in order to achieve optimal oil and maximized production capacity.

DHZ series disc centrifuge for vegetable oil refining are widely used in continuous degumming, neutralizing, dewaxing, and washing of vegetable oils .

Model	Treatment capacity (L/H)	Inlet Pressure (Mpa)	Outlet pressure (Mpa)	Motor power (Kw)	Weight (Kg)	Outline dimension (mm)
DHZ360	1200-2500	0.05	0.1-0.25	7.5	1280	150011501500
DHZ470	2500-7000	0.05	0.1-0.25	15	1880	180012001800
DHZ550A	5000-10000	0.05	0.1-0.25	18.5	2200	185015502050
DHZ550E	6000-15000	0.05	0.1-0.25	22	2200	185015502050
DHZ700	15000-30000	0.1	0.2	30	3300	210016502300
DRZ360	1200-2500	0.05	0.1-0.25	5.5	750	125010501500
DRZ400A	2000-6000	0.05	0.1-0.3	7.5	1150	13009001450
DRZ400E	4000-7500	0.05	0.1-0.3	7.5	1300	13009001500
DRZ550	6000-18000	0.05	0.1-0.3	22	2200	162013002200

Automatic Discharge Disc Bowl Oil Separator for Soybean Oil

Main Features

Higher production capacity
Continuous feeding
High separation factor
Automatic residue discharging

Lower maintenance costs
Concise bowl design without frequent washing
Hydraulic coupling driving with longer service life

No need of manual monitoring
PLC automatic control

Certifications

Detailed Images

Machine Parts

Name: Separator disc

Brand: Juneng

Original: China

Domestic famous engines

Main Parts

Name: Separator shaft
Brand: Juneng
Original: China

Vertical shaft, cross shaft

Machine Parts

Name: Separator drum
Brand: Juneng
Original: China
Domestic famous engines

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
